+35 (191) 2036503
AIDFLEX x3
Universal verticalizer
AIDFLEX X3
Universal verticalizer for restoration and high-quality prevention of the musculoskeletal system
Why is it necessary to verticalize?
Activation of biologically important processes
Restoration of vertical position static stereotype and training of orthostatic reactions
Improving balance and coordination
Performing exercises in a natural standing position activates the muscles responsible for maintaining a vertical posture
Stimulation of intestinal and urinary bladder activity
Standing position improves intestinal peristalsis along with the kidney and bladder activity
Improving the function of the cardiovascular and respiratory systems
Restoration of vertical position static stereotype and training of orthostatic reactions
Prevention of osteoporosis and contracture
Performing exercises in a natural standing position activates the muscles responsible for maintaining a vertical posture
Features of complete sets
- Individual
- Comfort
- Clinic
AIDFLEX X3
Aidflex Therapy
The versatility of Aidflex MFTR system allowed to extend the range of potential therapeutic effects and to create a unique and comprehensive «Aidflex Therapy» physical rehabilitation program.
Aidflex MFTR is developed to help in overcoming the barriers on the way to conscious, biomechanically correct motions, which, being simple for a healthy person, are difficult and inaccessible for people with diseases and injuries of central nervous system.
Aidflex MFTR is developed to help in overcoming the barriers on the way to conscious, biomechanically correct motions, which, being simple for a healthy person, are difficult and inaccessible for people with diseases and injuries of central nervous system.
Gentle verticalization
The verticalizer has a unique design, lifting levers first gently lift the patient vertically, using a soft belt directly under the pelvis, then pull the pelvis forward reducing the load on the knee joints. Handrails on the lifting levers allow you to control the position of the torso during the lifting process
Comfortable support for arms. It allows to safely perform exercises in a standing position while maintaining balance with the arms - good for strengthening the core muscles
Adjustable handrails. Additional grip extends comfort and capabilities
Table with a soft rest for the front of the body and additional fixation from the back
Easy table adjustment. Gas spring allows you to adjust the height of the table without much effort
Adjustable table
Adjustable handrails
Жесткая рама. Несущая рама тренажера имеет направляющие для крепления вдоль всего профиля и позволяет выдерживать нагрузки в любой точке приложения усилия.
Силовые стойки с удлиняемым тросом. Силовые стойки за счет удлиняемого троса позволяют перенаправлять усилие в любую точку вокруг пациента. Это позволяет как создавать нужное сопротивление, так и разгружать части тела пациента.
Разгрузочная система. Позволяет создавать стационарные точки подвеса и перенаправлять как усилие от силовых стоек, так и от подъемника, работая самостоятельно или в сочетании со слайдерной системой.
Позволяет создавать стационарные точки подвеса и перенаправлять как усилие от силовых стоек, так и от подъемника, работая самостоятельно или в сочетании со слайдерной системой.
Подъемная кушетка. Кушетка оснащена электрической регулировкой высоты как для удобства работы специалистов разного роста, так и для плавной разгрузки пациента.
Компактный. Полноценная реабилитация движением на одном рабочем месте в 6 м.кв. В варианте крепления к стене в сложенном виде не более 1 м.кв. по полу.
Молульный. Тренажер компонуется из готовых модулей для решения конкретных задач.
Разгрузочная система.
Knee supports
Feet holders. Are regulated on the plane, are fixed in one motion
Independent 3-way knee supports
Feet holders
Safety belts. The possibility of additional fixation at the level of the knees, lower back and chest
Жесткая рама. Несущая рама тренажера имеет направляющие для крепления вдоль всего профиля и позволяет выдерживать нагрузки в любой точке приложения усилия.
Силовые стойки с удлиняемым тросом. Силовые стойки за счет удлиняемого троса позволяют перенаправлять усилие в любую точку вокруг пациента. Это позволяет как создавать нужное сопротивление, так и разгружать части тела пациента.
Разгрузочная система. Позволяет создавать стационарные точки подвеса и перенаправлять как усилие от силовых стоек, так и от подъемника, работая самостоятельно или в сочетании со слайдерной системой.
Позволяет создавать стационарные точки подвеса и перенаправлять как усилие от силовых стоек, так и от подъемника, работая самостоятельно или в сочетании со слайдерной системой.
Подъемная кушетка. Кушетка оснащена электрической регулировкой высоты как для удобства работы специалистов разного роста, так и для плавной разгрузки пациента.
Компактный. Полноценная реабилитация движением на одном рабочем месте в 6 м.кв. В варианте крепления к стене в сложенном виде не более 1 м.кв. по полу.
Молульный. Тренажер компонуется из готовых модулей для решения конкретных задач.
Разгрузочная система.
Sliding supports
Sliding supports for wheelchair access.
This allows the device to get closer to the wheelchair, which translates into comfort and safety
This allows the device to get closer to the wheelchair, which translates into comfort and safety
Lifting handles.
While lifting the handles allow you to independently control the position of the body
While lifting the handles allow you to independently control the position of the body
Manual lowering.
In case of lack or interruption of electricity
In case of lack or interruption of electricity
Battery.
Option that allows you to use the G9 wireless
Option that allows you to use the G9 wireless
Lifting handles
Three easy steps to verticalize
STEP 1
Place your feet on the foot holders
Convenient adjustment of foot holders and knee pads in 3 planes
STEP 2
Place the lifting belt under the pelvis
The belt allows you to verticalize without having to change to the machine
STEP 3
Start the lifting mechanism
The Airflex X3 is equipped with an electromechanical drive with a safe descent function
The following diseases can be treated on the AIDFLEX X3 equipment
Stroke
Head injury
Spinal Injury
CNS infections and intoxications
Polyradiculoneuropathy
Multiple sclerosis
Lower paraparesis
Hemiparesis
Head injury
Spinal Injury
CNS infections and intoxications
Polyradiculoneuropathy
Multiple sclerosis
Lower paraparesis
Hemiparesis
Therapy and medical rehabilitation
AIDFLEX X3 «Individual-100»
3 405 €
р.
This option is suited for patients with flaccid paraparesis of the lower extremities, hemiparesis, hypotension of the lower extremities. The patient should be able to confidently sit in a wheelchair and hold his back.
Patient weight up to 100 kg.
Adjustments of feet holders, knees and table depth are carried out using an Allen key.
Table without handrails.
Recommended for personal use when frequent setup is not required.
Patient weight up to 100 kg.
Adjustments of feet holders, knees and table depth are carried out using an Allen key.
Table without handrails.
Recommended for personal use when frequent setup is not required.
Закрыть
AIDFLEX X3 «Individual-130»
3 753 €
р.
This option is well suited for patients with flaccid paraparesis of the lower extremities, hemiparesis, hypotension of the lower extremities. The patient should be able to confidently sit in a wheelchair and hold his back.
Patient weight up to 130 kg.
Adjustments of Feet holders, knees and table depth are carried out using an Allen key.
Table without handrails.
Recommended for personal use when frequent setup is not required.
Patient weight up to 130 kg.
Adjustments of Feet holders, knees and table depth are carried out using an Allen key.
Table without handrails.
Recommended for personal use when frequent setup is not required.
Закрыть
AIDFLEX X3 «Comfort-100»
3 609 €
р.
This option is suitable for patients with flaccid or spastic paraparesis of the lower extremities, hemiparesis, tetraparesis. The user must have sufficient strength in the hands to maintain the torso in an upright position with the help of handrails.
Patient weight up to 100 kg.
Feet holders are adjusted using a hex wrench.
Table with handrails.
Quick-release handles for access through doorways.
Adjustable elbows.
The kit includes straps for the knee and upper torso.
Recommended for home use.
Convenient for passage through doors.
Allows you to train with a fixed body and palm rest
Patient weight up to 100 kg.
Feet holders are adjusted using a hex wrench.
Table with handrails.
Quick-release handles for access through doorways.
Adjustable elbows.
The kit includes straps for the knee and upper torso.
Recommended for home use.
Convenient for passage through doors.
Allows you to train with a fixed body and palm rest
Закрыть
AIDFLEX X3 «Comfort-130»
3 957 €
р.
This option is suitable for patients with flaccid or spastic paraparesis of the lower extremities, hemiparesis, tetraparesis. The user must have sufficient strength in the hands to maintain the torso in an upright position with the help of handrails.
Patient weight up to 130 kg.
Feet holders are adjusted using a hex wrench.
Table with handrails.
Quick-release handles for access through doorways.
Adjustable elbows.
The kit includes straps for the knee and upper torso.
Recommended for home use.
Convenient for passage through doors.
Allows you to train with a fixed body and palm rest.
Patient weight up to 130 kg.
Feet holders are adjusted using a hex wrench.
Table with handrails.
Quick-release handles for access through doorways.
Adjustable elbows.
The kit includes straps for the knee and upper torso.
Recommended for home use.
Convenient for passage through doors.
Allows you to train with a fixed body and palm rest.
Закрыть
AIDFLEX X3 «Clinic»
4 495 €
р.
This option is well suited for patients with flaccid or spastic paraparesis of the lower extremities, hemiparesis, tetraparesis. The user must have sufficient strength in the hands to maintain the torso in an upright position with the help of handrails. This equipment can be quickly adapted to individual orthopedic features / limitations of the knee and hip joints.
Patient weight up to 130 kg.
Quick and complete adjustments.
Table with handrails.
Quick detachable handles.
Accumulator battery.
The kit includes straps for the knee and upper torso.
Recommended for use in clinics and places of mass use.
Patient weight up to 130 kg.
Quick and complete adjustments.
Table with handrails.
Quick detachable handles.
Accumulator battery.
The kit includes straps for the knee and upper torso.
Recommended for use in clinics and places of mass use.
Закрыть
Specification
Equipment features
1. Overall dimensions: (LxWxH)
1050х710х1165 mm
2. Minimum doorway width (with folded handles)
720 mm
3. Weight
63 kg
4. User height
150-195 cm
5. User weight limit
135/150 kg
6. Feet holders depth adjustment
±35 mm
7. Feet holders width adjustment
±50 mm
8. Feet holders angle adjustment
±20°
9. Knee supports height adjustment
±100 mm
10. Knee supports depth adjustment
±85 mm
11. Waist supports height adjustment
±115 mm
12. Waist support depth adjustment
±115 mm
13. Adjustment range table’s handles
120 mm
14. U-turn table's handles
180°
15. Polyurethane chippers in the corners
yes
16. Adjustment table straps
yes
17. Adjustment kneepads straps
yes
18. Adjustment straps for lumbar and thoracic zone
yes
19. Sliding supports for wheelchair access
yes
20. Castors with brakes
yes
21. Power supply
120-240В,
50/60Hz, max 3,9А
50/60Hz, max 3,9А
22. Manual lowering in the absence of electricity (option)
yes
23. Battery (option)
yes
Accessories
Expand the machine capabilities
If you have additional questions about this equipment, please contact us
Necessary verticalization
Universal verticalizer for restoration and high-quality prevention of the musculoskeletal system
The verticalizer is necessary for people with motor disorders in the lower extremities, which leads to the inability to independently adopt a vertical position. Regular use of the Aidflex X3 accelerates the recovery process, supports normal orthostatic reactions to a change in body position.
Stimulates the positonic and dynamic activity of vestibular and postural reflexes. Improves respiratory function, reflex mechanism of bowel and bladder emptying. Physical and axial loads in a standing position cause an increase in the piezoelectric charge on the bone tissue, which reduces the ability of osteoclasts to destroy bone, while osteoblasts continue to strengthen it.
Being in a natural upright position significantly improves the quality of life and the psycho-emotional state of a person.
Unlike the lift, the verticalizer is not only responsible for moving and lifting the patient, it allows you to safely fix the human body in the correct vertical position. And perform exercises in a natural physiological position while standing on their feet.
Being in a natural upright position significantly improves the quality of life and the psycho-emotional state of a person.
Unlike the lift, the verticalizer is not only responsible for moving and lifting the patient, it allows you to safely fix the human body in the correct vertical position. And perform exercises in a natural physiological position while standing on their feet.
